2007 Dodge Ram 3500 Clock Spring, Airbag, Air Bag Control Module, Air Bag Sensor

Air Bag Control Module, Air Bag Sensor, Airbag, Clock Spring Installation and Repair Tips for 2007 Dodge Ram 3500

• Q:

  How to Remove the Clock Spring Assembly on 2007 Dodge Ram 3500?

  A:

  The Clock Spring Assembly can be removed by disabling the airbag system by disconnecting the battery. Unfold driver airbag, steering wheel and shrouds. Unscrew wire harness and disconnect connector screws on Clock Spring. Reusing: in case of reusing, the rotor must be secured to ensure centering until it is reinstalled; otherwise, it must be centred prior to reinstalation.
• Q:

  How to Safely Service and Repair an Air Bag Control Module on 2007 Dodge Ram 3500?

  A:

  To maintain the Air Bag Control Module, one has to disable the supplemental restraint system by disconnecting the battery negative cable and wait two minutes. The occupant restraint controller (ORC) should not be dropped in order to avoid damage. Take out the ORC cover, and wire harness connectors, and securing nuts to take out the ORC.
• Q:

  How to Replace a Damaged or Ineffective Airbag on 2007 Dodge Ram 3500?

  A:

  In order to replace side curtain air bag, disable supplemental restraint system by removing the battery negative cable. Put on protective equipment when working with the air bag. Installation of the air bag, connecting it with screws, reconnection of the harness and tether clips. Install back the headliner and leave the battery unconnected until testing is done.
• Q:

  How to Service the Air Bag Sensor on a Quad Cab on 2007 Dodge Ram 3500?

  A:

  To service the side impact sensor in a Quad Cab, turn off the supplemental restraint system by disconnecting the negative battery cable. Handle the sensor carefully, if dropped replace it. The sensor should then be positioned in the B-pillar, held in place, and the stud tightened. Perform a verification test before starting the battery back on.
