2008 Chrysler Pacifica Door Hinge, Door Check, Door Latch Assembly, Exterior Door Handle

Door Check, Door Hinge, Door Latch Assembly, Exterior Door Handle Installation and Repair Tips for 2008 Chrysler Pacifica

• Q:

  How to Install a Front Exterior Door Handle on 2008 Chrysler Pacifica?

  A:

  To Install Front Door Exterior Handle Attach the outside handle bracket to the door with screws at 4 Nm torque. Insert the pivot leg of the handle, push it into position and fix it. Connect door lock and latch linkages, check operation and install watershield and trim panel.
• Q:

  How to Service and Repair a Front Door Hinge on 2008 Chrysler Pacifica?

  A:

  To replace the front door hinge, open the door and remove the check strap. Mark the hinge footprint, support the door, then remove the bolts connecting the hinge to the A-pillar and the door. Finally, detach the door hinge from the vehicle.
• Q:

  How to Install a Front Door Check on 2008 Chrysler Pacifica?

  A:

  Installation of the front door check requires the installation of the check strap through the speaker hole and using nuts every 12 Nm to secure the check strap on the door frame. Install door speaker, watershield and trim panel. Lastly, screw the check strap on the A-pillar to 12 Nm.
• Q:

  How to Service and Repair a Door Latch Assembly on 2008 Chrysler Pacifica?

  A:

  To service the rear door latch, remove the door trim panel and watershield, raise the door glass, and disconnect the clips for the lock and latch rods. If applicable, disengage the power door lock motor connector, then remove the screws and take out the latch from the door.
