2009 Chrysler Aspen Door Hinge, Door Check, Door Latch Assembly, Exterior Door Handle

Door Hinge, Door Latch Assembly, Exterior Door Handle Installation and Repair Tips for 2009 Chrysler Aspen

• Q:

  How to Install a Door Latch Assembly on 2009 Chrysler Aspen?

  A:

  The front door latch has to be installed by attaching to the door using the electrical connectors and actuator rods and tightening the screws to 10 Nm. Alignment is required, move the rear glass run channel, and tighten the nut and bolt to 8 Nm and install the watershield.
• Q:

  How to Remove a Front Exterior Door Handle on 2009 Chrysler Aspen?

  A:

  To remove the front exterior handle, first take off the watershield. Then, remove bolt 3 and nut 2, set aside the rear glass run channel, disconnect links from the latch, remove nut 4 and the handle, disconnect the electrical connector, and finally remove the lock cylinder.
• Q:

  How to Replace a Door Hinge Without Taking the Door Off on 2009 Chrysler Aspen?

  A:

  To change the rear door hinge without taking off the door, one at a time. Retain welded washers, so that the washers are not re-adjusted. Mark hinge positions and then get the required nuts and bolts of each upper and lower hinge and be careful to use body sealant in case they can be damaged during transfer.
