OEM Dodge Ram 2500 Van Drive Shaft

Dodge Ram 2500 Van Drive Shaft Parts and Q&A

• Drive Shaft
  52105410AA
  Q: How to service and repair the Drive Shaft on Dodge Ram 2500 Van?

  A:

  For service and repair of the drive/propeller shaft, first lift and stand the vehicle on safety supports and then put the transmission into Neutral. Make a mark across the axle pinion yoke or companion flange and down to the propeller shaft or companion yoke where the equipment will be installed. For Dana axles, take out the bolts that hold the universal joint clamps onto the pinion yoke. On Corporate axles, remove the bolts that secure the companion yoke to the companion flange. Take off the slip yoke from the transmission or transfer case output shaft and take out the propeller shaft. After that, place the slip yoke onto the output shaft of the transmission or transfer case and line up the reference marks on the propeller shaft or companion yoke and pinion yoke or companion flange when installing it. Insert the universal joint into the pinion yoke on a Dana axle and attach the universal joint strap bolts with a torque of 29 Nm (22 ft. lbs.). Attach the companion yoke onto the companion flange for Corporate axles and lug the bolts tightly to 108 Nm (80 ft. lbs.). Lastly, bring the car down.
• Drive Shaft
  52105412AA
  Q: How to remove and install the Drive Shaft on Dodge Ram 2500 Van?

  A:

  Raise the vehicle on safety stands and then shift the transmission into Neutral. Put marks across the axle pinion yoke or companion flange and the propeller shaft or companion yoke to guide installation. When working on Dana axles, take out the bolts that secure the universal joint clamps to the pinion yoke. Take out the bolts that hold the companion yoke to the companion flange for all Corporate axles. First, move the slip yoke from the output shaft of either the transmission or transfer case and then take off the propeller shaft. To install, place the slip yoke onto the end of the transmission or transfer case shaft and make sure that the installation marks on the propeller shaft or companion yoke are aligned with the pinion yoke or companion flange. Carefully place the universal joint into the pinion yoke in Dana axles and tighten the strap bolts until they reach 29 Nm (22 ft. lbs.). Put the companion yoke onto the companion flange and tighten its bolts to 108 Nm (80 ft. lbs.). The last step is to lower the vehicle.
