OEM 2006 Dodge Durango Tie Rod End

2006 Dodge Durango Tie Rod End Parts and Q&A

• Q: How to Service a Tie Rod End on 2006 Dodge Durango?

  A: The boot should not be turned while you remove or install the tie rod end. Remove 3, the jam nut, before taking out 1, the outer tie rod end nut from the ball stud. Use Remover 8677 to split apart the outer tie rod end 2 from the knuckle. Before taking apart the outer tie rod end from the inner tie rod 4, take note of how many times you turn it so you can remake and adjust the toe properly. For installing, place the outer tie rod end 2 over the inner tie rod 4 as before and then put it in the steering knuckle 5. Screw on the ball stud nut 1 until it reaches 75 Nm (55 ft. lbs.), mark the car's intended toe settings, then tighten nut 3 to 130 Nm (96 ft. lbs.).
