OEM Dodge Alternator Pulley

Dodge Alternator Pulley Parts and Q&A

• Pulley
  4861506AH
  Q: How to Maintain and Fix an Alternator Pulley on Dodge Grand Caravan?

  A:

  Begin your work by unlocking the car and popping up the hood and afterward, take out the negative battery terminal. Lift and prop up the vehicle and disconnect the right front lower splash shield. Next, take out the drive belt and lower the vehicle. After that, take out the Air Box and the decoupler pulley cover. Use Special Tool #8433 to get the Generator Decoupler loose and once it's fit, take out both the item and the tool. To install, connect the Generator Decoupler to the generator shaft and tighten it with Special Tool #8433, making sure you use the correct torque chart. Add on the pulley cover for the decoupler, Air Box, support the vehicle once more and attach the accessory drive belt. In the end, place the right front lower splash shield correctly, drop the car and reattach the negative battery cable.
• Pulley
  5117591AA
  Q: How to Service an Alternator Pulley on Dodge Sprinter 2500?

  A:

  To start with, detach the negative battery cable and take off the generator and accessory drive belt. To fit the INA decoupler, insert Special Tool #8823 (VM.1048) into place and check the end of the generator shaft; if hex-shaped, use a 10 MM deep socket, otherwise if it has a spline, use either a 5/16" 6-point hex driver or a 10 MM 12-point triple square driver. Turn the tool clockwise to break the decoupler free and after that unthread it manually. To work on the Litens decoupler, also unplug the negative battery cable and take off the generator and belt, then enter Special Tool #8433 into the decoupler and line it up with the generator's hex end. After that, turn the tool so the notches face clockwise and unscrew the decoupler by hand. Install the INA decoupler by hand-threading the pulley onto the generator shaft, positioning Special Tool #8823 (VM.1048) and using the usual socket or driver. To tighten the bolts, use a torque wrench set to the correct torque numbers and turn in the opposite direction to finish. After that, put on the accessory drive belt and generator and reconnect the negative battery cable. When using a Litens decoupler, use the same threading and tool placement, plus the specified torque wrench and procedures.
