How to Service the Dual Zone Passenger Side Blend Door Actuator on Dodge Ram 1500?

Before working on the dual zone passenger side air door actuator, remove the battery cable on the negative side and let the system wait for two minutes for the air bag capacitor to drain. First, remove the instrument panel from the car. Following that, unlink the blend door lever from the blend door actuator output shaft as well as from the blend door linkage. Remove the top of the HVAC housing by taking out the two screws binding the assembly to the Blend door actuator and bracket. Then, take out the assembly, releasing the wire harness connector from the actuator. Attach the actuator and bracket onto the HVAC housing and fix them using screws that are tightened to 2.2 N.m (20 in.lbs.). Match the guide pin at the base of the blend door actuator with the guides on the blend door linkage as you connect the wire harness to the connector. Then, fix the blend door lever on the output shaft of the actuator and on the blend door linkage, place the instrument panel again and join the negative battery cable.

How to replace a Blend Door Actuator on Dodge Ram 1500?

To start replacing the actuator, disable the air bag system by isolating the battery's negative cable and then allow at least two minutes for the air bag capacitor to discharge so you don't accidentally set off the air bag. There is only one blend door actuator in the single zone system, but two are used in a dual zone system, one for each side. You should begin by taking out the instrument panel and untying the wire harness from the blend door actuator. After that, unscrew the actuator(s) from inside the HVAC housing and set them aside. Guide the actuator(s) into the HVAC housing with the splines on the actuator output sleeve(s) fitting over the blend door linkage. Secure your actuator with screws tightened to just 2 Nm (17 in. lbs.), attach the HVAC wire harness connector, replace the instrument panel and attach the battery negative cable.
